240kW Induction Furnace for Melting and Casting – Top China Suppliers and Factory for Pb, Zn, Cu, and Cast Iron

240kW Induction Furnace for Melting and Casting – Top China Suppliers and Factory for Pb, Zn, Cu, and Cast Iron

Introducing our advanced industrial frequency induction furnace, designed to meet the melting and casting needs of various metals. This high-performance furnace comprises a robust furnace body, superior refractory materials, an efficient feeding system, and a comprehensive cooling system. Additionally, it features a reliable inductor, a sophisticated electrical control system, and an effective ingot casting system. Perfect for melting and thermally insulating Pb, Zn, Cu, and cast iron, our induction furnaces are manufactured in China and supplied by leading suppliers in the industry. Trust our factory to provide you with top-quality equipment for your metal processing requirements.

    Contact us
    Product Details

    Key Features
    Dismountable inductor, easy to replace.
    Special structure of melting channel ensures small temperature difference and longer inductor service life.
    Furnace wall poured by low cement material for superior integrity and sealing.
    Advanced overvoltage and overcurrent protection with automatic alarm/shutdown functions.
    Specially researched inductor material optimized for Zn smelting.
    Computer numerical simulation technology used for optimized melting groove design.
    Optimum quality silicon steel sheet iron core to minimize iron loss.
    High Zn direct recovery rate: ≥97%.
    Low energy consumption: 110~115kWh/t.
    Eco-friendly: Less smoke than rotary furnaces, improved working conditions.
    High unit output capacity.
    Product Parts
    Inductor
    Inductor
    Furnace Body
    Furnace Body
    Graphite Ladle
    Graphite Ladle
    Casting Machine
    Casting Machine
    Feeder
    Feeder
    Technical Parameters
    Model Capacity Power Inductor Qty Voltage
    GYX-100-2000 100t 2000kW 2 380V
    GYX-100-2000 100t 2000kW 3 660V
    GYX-60-1200 60t 1200kW 4 500V
    GYX-50-960 50t 960kW 3 380V
    GYX-50-900 50t 900kW 3 380V
    GYX-45-900 45t 900kW 3 380V
    GYX-40-800 40t 800kW 2 500V
    GYX-50-720 50t 720kW 3 380V
    GYX-40-720 40t 720kW 3 380V
    GYX-40-600 40t 600kW 2 380V
    GYX-35-600 35t 600kW 2 380V
    GYX-32-540 32t 540kW 6 380V
    GYX-32-480 32t 480kW 2 380V
    GYX-32-480 32t 480kW 6 380V
    GYX-25-360 25t 360kW 2 380V
    GYX-25-360 25t 360kW 6 380V
    GYX-15-240 15t 240kW 2 380V
    GYX-15-240 15t 240kW 3 380V
    GYX-12-180 12t 180kW/240kW 1 380V
    GYX-10-400 10t 400kW 1 500V
    GYX-6-400 6t 180kW 1 380V
    Frequently Asked Questions
    1. What are your prices?
    Our prices are subject to the specific model and configuration required for your project.
    2. Can you supply the relevant documentation?
    Yes, we can provide most documentation including Certificates of Analysis / Conformance, Insurance, Origin, and other required export documents.
    3. What is the average lead time?
    The average lead time is typically 3 months following the receipt of the advance payment.
    4. What kinds of payment methods do you accept?
    Payment terms are negotiable to suit both parties' requirements.
    5. Do you provide installation and commissioning services?
    Yes, we provide professional technical guidance for installation and commissioning to ensure optimal performance of the furnace.
    6. How do you ensure the energy efficiency of the furnace?
    Our furnaces utilize high-quality silicon steel sheets and computer-optimized melting channel designs to minimize energy loss, achieving 110~115kWh/t.
