Short Description:

To achieve the melting and casting function, a set of industrial-use frequency induction furnace is consisted of furnace body, refractory material, feeding system, cooling system, inductor, electrical control system and ingot casting system. This equipment is mainly used in melting and thermal insulation procedures of Pb, Zn, Cu and cast iron.

Product Detail

Product Tags


(1)Dismountable inductor, easy to replace.
(2)Special structure of melting channel ensures the small temperature difference between the molten metal and the hearth, which makes longer service life of the inductors.
(3)The furnace wall is poured by low cement material, which has better integrity and sealing property.
(4)Equipped with Overvoltage and overcurrent protection devices, when the cooling air temperature of inductor is too high, the furnace has automatic alarm and shutdown function.

Technical Parameters

Model Capacity Power Inductor Qty Voltage
GYX-100-2000 100t 2000kW 2 380V
GYX-100-2000 100t 2000kW 3 660V
GYX-60-1200 60t 1200kW 4 500V
GYX-50-960 50t 960kW 3 380V
GYX-50-900 50t 900kW 3 380V
GYX-45-900 45t 900kW 3 380V
GYX-40-800 40t 800kW 2 500V
GYX-50-720 50t 720kW 3 380V
GYX-40-72 40t 720kW 3 380V
GYX-40-600 40t 600kW 2 380V
GYX-35-600 35t 600kW 2 380V
GYX-32-540 32t 540kW 6 380V
GYX-32-480 32t 480kW 2 380V
GYX-32-480 32t 480kW 6 380V
GYX-25-360 25t 360kW 2 380V
GYX-25-360 25t 360kW 6 380V
GYX-15-240 15t 240kW 2 380V
GYX-15-240 15t 240kW 3 380V
GYX-12-180 12t 180kW/240kW 1 380V
GYX-10-400 10t 400kW 1 500V
GYX-6-400 6t 180kW 1 380V


1.What are your prices?
Our prices are subject to model.

2.Can you supply the relevant documentation?
Yes, we can provide most documentation including Certificates of Analysis / Conformance; Insurance; Origin, and other export documents where required.

3.What is the average lead time?
The average lead time would be 3 months after advance payment.

4.What kinds of payment methods do you accept?
